The 5–45×56 PM II High Power is a professional‑grade precision optic that merges a high‑performance riflescope with spotting‑scope capability. Designed for observation and ultra‑long‑range engagement, its enormous 9× zoom range (5–45×) makes it equally at home on reconnaissance, match, or tactical platforms where both identification and shot‑making accuracy are required.
Engineered for extreme clarity and reach, the 56 mm objective delivers excellent light gathering while the optical system maintains a large usable field of view across the entire zoom range — allowing fast situational awareness at low magnification and razor‑sharp detail at high power. The reticle sits in the first focal plane, so hold‑offs and subtensions remain precise at any magnification. The model features robust, lockable turrets with fine 0.1 mrad click values and very large usable internal adjustment ranges tailored for extreme‑range correction.
Built on a rugged 34 mm main tube, the High Power is constructed for demanding environments: it is fully weatherproof, fogproof and shock‑resistant. Despite its long reach, the design balances mechanical strength with practical ergonomics for field use.
Standout Features
Exceptional 5–45× magnification range for combined observation and precision shooting
Large 56 mm objective for outstanding light transmission and image resolution
First focal plane reticle for accurate ranging and holdover at any magnification
Precision turrets with 0.1 mrad click value and extensive elevation/windage adjustment range
Side/parallax adjustment for crisp focus from mid‑range to extreme distances
High optical transmission (~90%) and illuminated reticle options for low‑light operations
Robust 34 mm tube, weatherproof and built for professional use
Key Specifications
Magnification: 5–45×
Objective diameter: 56 mm
Main tube diameter: 34 mm
Field of view: approx. 7.8–0.9 m @ 100 m
Exit pupil: approx. 8.8–1.2 mm
Eye relief: 90 mm
Length: approx. 434 mm
Weight: approx. 1,130 g
Reticle: FFP (various tactical reticle options)
Click value: 0.1 mrad
Elevation adjustment range: ~27 mrad (internal ~29.6 mrad)
Windage adjustment range: ±6 mrad (internal ~21.1 mrad)
Parallax: adjustable
Illumination levels: multiple (illuminated reticle available)
Optical transmission: ~90%
Designed and manufactured to professional standards, the 5–45×56 PM II High Power is the go‑to optic for operators and precision shooters who require unmatched versatility, extreme reach and uncompromising optical and mechanical performance.
Entdecke das 5–45x56 PM II High Power – die perfekte Optik für Präzisionsschützen!
Das 5–45×56 PM II High Power ist ein professionelles Präzisionsvisier, das die Vorteile eines Hochleistungszielfernrohrs mit der Fähigkeit eines Beobachtungsfernrohrs kombiniert. Es wurde für die Beobachtung und ultra-langstrecken Einsätze entwickelt und bietet einen enormen 9-fachen Zoombereich (5–45×), der es sowohl für Aufklärungs-, Wettkampf- als auch taktische Plattformen geeignet macht, bei denen sowohl Identifikation als auch Schussgenauigkeit erforderlich sind.
Hauptmerkmale
- Außergewöhnlicher 5–45× Vergrößerungsbereich für kombinierte Beobachtung und präzises Schießen
- Großes 56 mm Objektiv für hervorragende Lichtübertragung und Bildauflösung
- Absehen im ersten Fokusplane für präzises Messen und Haltepunktkorrekturen bei jeder Vergrößerung
- Präzise Türme mit 0,1 mrad Klickwert und umfangreichen Höhen-/Seitenverstellbereichen
- Seiten-/Parallaxeverstellung für scharfen Fokus von mittleren bis extremen Distanzen
- Hohe optische Übertragung (~90%) und beleuchtete Absehen-Optionen für Einsätze bei schwachem Licht
- Robuster 34 mm Tubus, wetterfest und für den professionellen Einsatz gebaut
Technische Spezifikationen
- Vergrößerung: 5–45×
- Objektivdurchmesser: 56 mm
- Durchmesser des Hauptrohrs: 34 mm
- Sichtfeld: ca. 7,8–0,9 m @ 100 m
- Austrittpupille: ca. 8,8–1,2 mm
- Augenabstand: 90 mm
- Länge: ca. 434 mm
- Gewicht: ca. 1.130 g
- Absehen: FFP (verschiedene taktische Absehen-Optionen)
- Klickwert: 0,1 mrad
- Höhenverstellbereich: ~27 mrad (intern ~29,6 mrad)
- Seitenverstellbereich: ±6 mrad (intern ~21,1 mrad)
- Parallaxeverstellung: einstellbar
- Beleuchtungsstufen: mehrere (beleuchtetes Absehen verfügbar)
- Optische Übertragung: ~90%
Das 5–45×56 PM II High Power wurde nach professionellen Standards entworfen und hergestellt und ist die erste Wahl für Operatoren und Präzisionsschützen, die unvergleichliche Vielseitigkeit, extreme Reichweite und kompromisslose optische sowie mechanische Leistung benötigen.
